Solar Connectors

Solar Connectors - TSC

TSC

"TSC" connectors are designed for connecting solar panels in photovoltaic installations. They have a universal shape type MC4 connectors.

Raw materials

- Body:
6 mm²: Polycarbonate and polyamide 6.6 with 25% glass fiber, V0 (according to UL94)
10 mm²: Polyethylene, V0 (according to UL94)
- Insert Borne: Tinner copper
IP Rate: IP68

Series TSC

Venta/distribuidor/mayorista Conector SMD de conexión rápida. Válido para cables desde 0.2 mm² hasta 0.75 mm² rígidos o flexibles, fácilmente extraíbles.SMD 1P

TSC4/M

TSC Male Connector

Connection capacity:

- Solid cable: 2,5 mm² / 6 mm²

- Flexible cable: 2,5 mm² / 6 mm²

Voltage: 1500V

Temperature: -40ºC+85ºC

Intensity: 30A - 2,5mm² 35A - 4mm² 50A - 6mm²

TSC4/H

TSC Female Connector

Connection capacity:

- Solid cable: 2,5 mm² / 6 mm²

- Flexible cable: 2,5 mm² / 6 mm²

Voltage: 1500V

Temperature: -40ºC+85ºC

Intensity: 30A - 2,5mm² 35A - 4mm² 50A - 6mm²

TSC10/M

TSC Male Connector

Connection capacity:

- Solid cable: 6 mm² / 10 mm²

- Flexible cable: 6 mm² / 10 mm²

Voltage: 1500V

Temperature: -40ºC+85ºC

Intensity: 54A - 6mm² 70A -10mm²

TSC10/H

TSC Female Connector

Connection capacity:

- Solid cable: 6 mm² / 10 mm²

- Flexible cable: 6 mm² / 10 mm²

Voltage: 1500V

Temperature: -40ºC+85ºC

Intensity: 54A - 6mm² 70A -10mm²

ACCESSORIES

TSC10/TOOL

Tool to facilitate the assembly
