CONECTORES PARA PCB TK5000

TK5000

PBC terminal block.

CE
VDE
HALOGEN FREE
ROHS
Raw materials

- Moulding:
    - Standard: Polyamide 6. Natural colour. V2 (according to UL 94).
    - V0: Polyamide 6.6, cream colour. V0 (according to UL 94).
- Insert: tinned brass.
- Screws: zinc-plated steel. Metric thread.

Constructive characteristics

- Poles: 1 to 12.
- Horizontal or vertical pin.
- Horizontal version: the length of the insert has been enlarged to improve the connexion (greater security).
- Larger screw head to get a faster and easier tightening (saving time and less effort).
- The diameter of the pin has been increased to prevent breakage (greater security).
- Raised screw and bigger connection hole providing an easier insertion of conductor.
- Several possibilities to fix strip (soldering pin, screw…).

TK 5000 Series

Connectors used for making electrical connections in circuit cards boards.

Available pre-cut and printed upon-request.

TK5000 H4,5

Printed Circuit Strips

Connection capacity:

- Solid cable: 2,5 mm² / 1 mm²

- Flexible cable: 2,5 mm² / 1 mm²

Voltage: 450 V

Temperature: 110 ºC

Constructive:

- Poles: 1 to 12.
- Horizontal pin.
- Horizontal version: the length of the insert has been enlarged to improve the connexion (greater security).
- Larger screw head to get a faster and easier tightening (saving time and less effort).
- The diameter of the pin has been increased to prevent breakage (greater security).
- Raised screw and bigger connection hole providing an easier insertion of conductor.
- Several possibilities to fix strip (soldering pin, screw…).

Intensity: 24 A

Tightening torque: 0,5 Nm

Metrics: M 3

Type: Horizontal pin

TK5000 H4,5 V0

Printed Circuit Strips

Connection capacity:

- Solid cable: 2,5 mm² / 1 mm²

- Flexible cable: 2,5 mm² / 1 mm²

Voltage: 450 V

Temperature: 150 ºC

Constructive:

- Poles: 1 to 12.
- Horizontal pin.
- Horizontal version: the length of the insert has been enlarged to improve the connexion (greater security).
- Larger screw head to get a faster and easier tightening (saving time and less effort).
- The diameter of the pin has been increased to prevent breakage (greater security).
- Raised screw and bigger connection hole providing an easier insertion of conductor.
- Several possibilities to fix strip (soldering pin, screw…).

Intensity: 24 A

Tightening torque: 0,5 Nm

Metrics: M 3

Type: Horizontal pin

TK5000 V4,5

Printed Circuit Strips

Connection capacity:

- Solid cable: 2,5 mm² / 1 mm²

- Flexible cable: 2,5 mm² / 1 mm²

Voltage: 450 V

Temperature: 110 ºC

Constructive:

- Poles: 1 to 12.
- Vertical pin.
- Larger screw head to get a faster and easier tightening (saving time and less effort).
- The diameter of the pin has been increased to prevent breakage (greater security).
- Raised screw and bigger connection hole providing an easier insertion of conductor.
- Several possibilities to fix strip (soldering pin, screw…).

Intensity: 24 A

Tightening torque: 0,5 Nm

Metrics: M 3

Type: Vertical pin

TK5000 V4,5 V0

Printed Circuit Strips

Connection capacity:

- Solid cable: 2,5 mm² / 1 mm²

- Flexible cable: 2,5 mm² / 1 mm²

Voltage: 450 V

Temperature: 150 ºC

Constructive:

- Poles: 1 to 12.
- Vertical pin.
- Larger screw head to get a faster and easier tightening (saving time and less effort).
- The diameter of the pin has been increased to prevent breakage (greater security).
- Raised screw and bigger connection hole providing an easier insertion of conductor.
- Several possibilities to fix strip (soldering pin, screw…).

Intensity: 24 A

Tightening torque: 0,5 Nm

Metrics: M 3

Type: Vertical pin
